16 Stations PVC Injection Molding Machine

Model No: 5116-YY | MOQ: 1 Set | Price: USD 37,700 | Weight: 11,500kg



Youdianman (Xiamen) Intelligent Technology Co., Ltd. proudly presents the 16 Stations PVC Injection Molding Machine, a high-performance system designed for mass production of high-quality shoe soles using PVC, TPR, and TR materials. Engineered with durability, automation, and efficiency in mind, this machine is ideal for manufacturers seeking consistent output, stable molding quality, and long-term reliability.





Model No:5116-YY

MOQ:1 set

Machine weight:11500kg

Product Prices: 37700USD





The 16 stations PVC injection molding machine can use materials such as TPR, TR, and PVC. With multiple workstations and long molding time, the 16 stations PVC injection molding machine can easily guarantee the quality of the shoe sole molding.





Raw material	TPR TR PVC
Number of stations	16 Stations
Screw Diameter	65mm/75mm
Screw rotating speed	0-200rpm
Screw length and diameter ratio	22：1
Max injection capacity	650/580cm³
Clamp mould style	Scissors
Shoe last height	210mm-260mm
Mould frame dimensions(L*W*H)	340mm*180mm*60mm
Total power	49.5kw
Motor power	31.5kw
Machine dimension(L*W*H)	7660mm*5200mm*1900mm
Injection pressure	5MPa
Disc pressure	3MPa





High Production Efficiency: With 16 rotary stations, this machine allows simultaneous injection and molding cycles, significantly increasing throughput.

Advanced Hydraulic System: Fully hydraulic drive and automatic cycling system ensure stable operation and easy maintenance.

Double-Pressure Injection: Equipped with a two-stage pressure injection system for precise control and better finished product quality.

Large Injection Capacity: Max injection volume of 650cm³ supports various sole types and thicknesses.

Intelligent PLC Control: Easy-to-use programmable logic controller ensures reliable and customizable operations.

Stable Heating System: Automatic temperature control for plasticizing provides consistent molding results.





Perfect for manufacturers of PVC, TR, and TPR shoe soles, sandals, boots, and slippers. This machine is a smart investment for factories aiming to boost productivity without compromising on quality.





Our machine is packaged in wooden crates to provide both convenient transportation and secure protection for the cargo. The sturdy wooden crates ensure that our machine is not only easy to handle during shipping but also fully shielded from possible damage during transit.









Q1: How much is the machine?
A: Please tell me the product requirements you need. The price varies with the machine configuration. Our machine can be customized.


Q2: What kind of payment method?
A: T/T or L/C


Q3: What materials can the machine use?
A: TPR ,TR, PVC


Q4: How many stations does the machine have?
A: 16,20,24
